UCS512C4 RGBW 24V 60灯/米 LED灯带
价钱
US $7.30 - US $7.50 / 米
HR00-UCS512C4-60-24
EXW
100 米
600000米 / 月
深圳
7-12天
UCS512C4灯带，UCS512C4 LED灯带，UCS512C4幻彩灯带，UCS512C4全彩灯带
数量
Welcome for your visit to our website. Established in 2010, Hanron has become a Leading led strip light manufacturer in China. By offering more than 2000 types of led strips, we've cooperated with 500+ customers in 78 countries.
Feature of dmx strip led
For UCS512C4 led strip:
1. Standard DMX512 signal, more stable signal transmission compare to SPI signal
2. No matter what or how many ic broken, the led strip will work normally.
DMX IC we use the 5 cable dmx512 double signal,256 grayscale high brightness fast data transfer fast screen refresh, etc. Using international standards DMX512 protocol products with one and multi-point damage do not affect other parts of the strips and continue work, etc.
3. DC24V design to allow a longer connection, more convenient during installation
4. It can work with Madrix and some DMX controllers to program
5. Only 10mm width in PCB, suitable for more types of aluminum profile
Specification
Item | Specification | Item | Specification |
Item Name | UCS512 dmx strip led | Light Source | 5050 RGBW |
IC Type | UCS512C4 | IC QTY | 10pixels/M |
LED QTY | 60leds/M | IC Location | External IC |
Color | RGBW Dream Color | Voltage | DC24V |
Working T | -20 to 45 Degree | Power | 19.2W/M |
PCB color | Black/White | Angle | 120 degrees |
IP Rating | IP20/65/66/68 | Cutting Unit | 10cm |
Package | Anti-Static Bag | OEM&ODM | Available |
Dimension | 5000mm*12mm | Lifetime | 50000hrs |
Certificate | ETL, CE, RoHS, Reach... | Warranty | 2years |
Dimension (mm)
IP Rating
Application of dmx strip led
