WS2811 / SM16703 / UCS1903 Addressable LED Strips
A WS2811 / SM16703 / UCS1903 LED strip is a digitally addressable LED strip that uses external ICs to control its lighting effects. Each IC controls one pixel segment, allowing different segments along the strip to display different colors or brightness levels and create effects such as chasing, flowing and color transitions.
Unlike strips that control every LED separately, this type of strip usually controls a group of LEDs as one pixel. For example, a 12V RGB strip with 60 LEDs/m and 20 pixels/m has three LEDs in each controllable pixel. The number of LEDs per pixel varies by model. These strips are available in 12V and 24V versions for applications such as signage, decorative lighting and architectural projects.
Related Knowledge:
1. The Ultimate Guide To Addressable LED Strip in 2026
2. How to Wire SPI Pixel Addressable LED Strip Light?
3. WS2811 VS WS2812 VS WS2813 VS WS2815 digital programmable LED strip
- 1
- 2
Features of WS2811 / SM16703 / UCS1903 LED Strips
Segment-based pixel effects
Each controllable segment can display a different color or brightness level, depending on the selected model. Check the pixels per meter and cutting length when planning the detail of your effects.
12V and 24V options
Choose from 12V and 24V models to suit your project. The appropriate power injection points depend on strip power, cable size and installed length.
Multiple color configurations
The range includes RGB, tunable white and chasing white strips. Select the color configuration first, then compare voltage, LED density and pixel density.
Options for custom projects
Tell us the required IC, PCB width, waterproof construction, cable length and order quantity. We can confirm which standard or customized model fits your project.
Specification
Model: WS2811 led strip
Data Speed: 800Kbps
Beam Angle: 120°
PCB Width: 8mm/10mm/12mm/20mm
Lifespan: 50,000 Hours
Operating Temperature: -20 ~ +65°C
IC Type :WS2811 IC
Working Voltage: DC12V
LED QTY: 30/60/90/96/102/144LEDs/M
IC QTY: 3led/pixel or 6LED/pixel
Frequency: 800Hz/s
Wave Length(nm): RED,650nm ; GREEN,520nm; BLUE，460nm
Gray Level: 256
Color: Full RGB Color 24-bit
PCB Color: White/Black/Yellow
IP Rating: IP20/IP65/IP66/IP68
Warranty: 3 Years
Package: 5M/roll with 1pcs 4Pin connector
WS2811 LED Strip Manufacturer in China
Hanron Lighting is a China-based manufacturer of WS2811, SM16703 and UCS1903 LED strips. Our range includes RGB, tunable white and chasing white models, with 12V and 24V options for different pixel lighting projects.
We also provide OEM and ODM services. Tell us your requirements for voltage, pixel density, PCB width, waterproofing or cable length, and our team can help you select an existing model or develop a customized solution. Certification documents are available for applicable models upon request.
Founded in 2010, Hanron Lighting has more than 100 employees, including 10 technical engineers and 20 sales engineers. Our manufacturing operations follow an ISO 9001:2015 certified quality management system.
Customized your WS2811 led strip is easy
Work with our team of 10 technical engineers
Need a WS2811, SM16703 or UCS1903 LED strip for a specific project? Hanron Lighting can help you adjust the strip design to match your installation and control requirements.
Customization options include:
1. LED density and pixels per meter
2. PCB width, color and shape
3. Color configuration, including RGB, tunable white and chasing white
4. 12V or 24V operation, subject to the selected design
5. Waterproof construction and adhesive backing
6. Cable length, connectors, and logo or packaging requirements
Send us your target specifications, drawings or application details. Our engineers will review the design and confirm the available options, technical specifications and production requirements.
Application of WS2811 LED Strip
WS2811 LED strips create chasing, flowing and color-changing effects through controllable pixel segments. They are suitable for decorative lighting，stage decoration lighting，electric bicycle ambient lighting，outdoor architectural lighting，E-sports venues，electronic game consoles，esports chairs, computer case lighting, etc.
Why Buy WS2811 LED Strips from Hanron Lighting?
Hanron offers the best quality led strip in the market
Quality Control
Our LED strips undergo inspections during production. Hanron Lighting operates under an ISO 9001:2015 certified quality management system, with a 3–5 year warranty available depending on the model.
Competitive Factory Pricing
As a China-based manufacturer, we can quote directly for standard models and custom projects. Share your specifications and order quantity to receive a price based on your requirements.
Reliable Production Capacity
Our team of more than 100 employees and automated production equipment supports both repeat orders and customized production. Lead time is confirmed for each order.
Low MOQ
We support small orders for standard WS2811 LED strip models, making it easier to test samples or start a project. MOQ varies by model, while customized strips may require a higher quantity.
Hanron Brand Certificate
ETL/CE/RoHS/Reach/CB/BIS/LM80/RCM
ISO9001:2015
ETL
CB
BIS
RCM
LM80 Test
CE EMC
CE LVD
CE RoHS
CE Reach
UKCA
IP68 Report
Factory Tour
100+ Employees to support your orders
FAQS
WS2811 strips use an external IC that typically controls a group of LEDs as one pixel. WS2812B integrates the control IC into each LED package, allowing each LED to be controlled separately. Our WS2811 series includes 12V and 24V models, while typical WS2812B strips operate at 5V. Choose according to the pixel detail, voltage and installation length your project requires.
WS2811 is a good starting point when your project or controller specifically calls for WS2811. SM16703 and UCS1903 can provide similar three-channel pixel effects, but their electrical and signal specifications are not identical. For example, the SM16703P and SM16703AP have different specified supply ranges and default output currents, while UCS1903 documentation describes both 400Kbps and 800Kbps data modes.
The best choice depends on the exact IC version, controller and LED strip design. If you need to replace an existing strip, send us the IC marking or controller model; we can confirm a suitable option before you order.
Each pixel is individually addressable, but each LED usually is not. One pixel may contain several LEDs that change together. For example, our 12V RGB model with 60 LEDs/m and 20 pixels/m controls three LEDs as one pixel. If you need control of every LED, ask us about a suitable single-LED-pixel model.
The WS2811 LED strip is more popular than other pixel LED strips because of the below reasons.
a. The WS2811 LED strip has less power drop compared to other LED strips because the WS2811 LED strip comes in 12V or 24V. So, you don’t require more power injection, which will save labor cost
b. The WS2811 LED strip has a single microcontroller. This microcontroller powers 3 LEDs or 6 LEDs per pixel, allowing the led in different places of the led strip to turn to different colors.
c. The color accuracy of WS2811 LED strips is better than general LED strips.
d. The price of the WS2811 LED strip is less than other pixel led strip light
Yes. If the receivers of two LED strips are the same, you can control two WS2811 LED strips with one remote.
So, check the compatibility of the receivers of WS2811 LED strips in case of illuminating big lighting projects with LED strips.
Multiply the strip length by its pixels per meter. For example, 5 m × 20 pixels/m = 100 pixels. If several strips are connected to one controller, include the pixels from every strip when checking controller capacity.
They may. Voltage drop depends on the strip’s power consumption, installed length and wiring. For longer runs, power may need to be supplied at both ends or at multiple points. Send us your layout and selected model so we can advise on the wiring plan.
