Hippo-M LED 连接器
最方便的 LED 灯带连接器
Hippo-M LED灯条连接器将为您的连接工作带来最大的便利。 它支持大多数具有不同二极管、宽度、FPC 厚度和防水方法的 LED 灯带类型，即使灯带上没有任何可见的焊盘。 此外，更多用户可以根据项目需求在现场轻松地将不同的电线连接到Hippo-M连接器上。 使用 Hippo-M LED 连接器，您的照明工作或业务将更加灵活。
Product Name: Hippo-M 2 Pin led strip connector
Item NO.: HR-N5XB2 HR-N5BB2
Type: strip to wire strip to strip joint
Dimension: 24.3*9.6*7.7mm 19.6*9.6*7.7mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃
Wire Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 5mm single color IP20, less than 121LEDs/M
Product Name: Hippo-M 2 Pin led strip connector
Item NO.: HR-N8XB2 HR-N8BB2
Type: strip to wire strip to strip joint
Dimension: 24.3*12.6*7.7mm 19.6*12.6*7.7mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃Wire
Gauge: 22-18AWG/0.32-0.78mm2
Workable Strip: 8mm single color IP20, less than 120LEDs/M
Product Name: Hippo-M 2 Pin led strip connector
Item NO.: HR-N8XB21 HR-N8BB21
Type: strip to wire strip to strip joint
Dimension: 24.3*12.6*7.7mm 19.6*12.6*7.7mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃
Wire Gauge: 22-18AWG/0.32-0.78mm2
Workable Strip: 8mm single color IP65, less than 121LEDs/M
Product Name: Hippo-M 2 Pin led strip connector
Item NO.: HR-N10XB2 HR-N10BB2
Type: strip to wire strip to strip joint
Dimension: 24.3*14.6*7.7mm 19.6*14.6*7.7mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃Wire
Gauge: 22-18AWG/0.32-0.78mm2
Workable Strip: 10mm single color IP20, less than 120LEDs/M
Product Name: Hippo-M 2 Pin led strip connector
Item NO.: HR-N10XB21 HR-N10BB21
Type: strip to wire strip to strip joint
Dimension: 24.3*14.6*7.7mm 19.6*14.6*7.7mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃
Wire Gauge: 22-18AWG/0.32-0.78mm2
Workable Strip: 10mm single color IP65, less than 121LEDs/M
Product Name: Hippo-M 2 Pin led strip connector
Item NO.: HR-N10XB2G HR-N10BB2G
Type: strip to wire strip to strip joint
Dimension: 24.3*14.6*7.7mm 19.6*14.6*7.7mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃Wire
Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 10mm single color IP20, less than 301LEDs/M
Product Name: Hippo-M 2 Pin led strip connector
Item NO.: HR-N12XB2 HR-N12BB2
Type: strip to wire strip to strip joint
Dimension: 24.3*17*7.8mm 19.6*17*7.8mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃
Wire Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 12mm single color IP20, less than 301LEDs/M
Product Name: Hippo-M 3 Pin led strip connector
Item NO.: HR-N10XB3 HR-N10BB3
Type: strip to wire strip to strip joint
Dimension: 24.3*14.6*7.7mm 19.6*14.6*7.7mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃Wire
Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 10mm single color IP20, less than 121LEDs/M
Product Name: Hippo-M 3 Pin led strip connector
Item NO.: HR-N10XB3 HR-N10BB3
Type: strip to wire strip to strip joint
Dimension: 24.3*14.6*7.7mm 19.6*14.6*7.7mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃
Wire Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 10mm dual color IP65, less than 121LEDs/M
Product Name: Hippo-M 4 Pin led strip connector
Item NO.: HR-N10XB4 HR-N10BB4
Type: strip to wire strip to strip joint
Dimension: 24.3*14.6*7.7mm 19.6*14.6*7.7mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃Wire
Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 10mm RGB IP20, less than 121LEDs/M
Product Name: Hippo-M 4 Pin led strip connector
Item NO.: HR-N10XB41 HR-N10BB41
Type: strip to wire strip to strip joint
Dimension: 24.3*14.6*7.7mm 19.6*14.6*7.7mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃
Wire Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 10mm RGB IP54/IP65, less than 121LEDs/M
Product Name: Hippo-M 5 Pin led strip connector
Item NO.: HR-N12XB5 HR-N12BB5
Type: strip to wire strip to strip joint
Dimension: 24.3*17*7.8mm 19.6*17*7.8mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃Wire
Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 12mm RGBW IP20, less than 91LEDs/M
Product Name: Hippo-M 5 Pin led strip connector
Item NO.: HR-N12XB5 HR-N12BB5
Type: strip to wire strip to strip joint
Dimension: 24.3*17*7.8mm 19.6*17*7.8mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃
Wire Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 12mm RGBW IP54/IP65, less than 91LEDs/M
Product Name: Hippo-M 6 Pin led strip connector
Item NO.: HR-N12XB6 HR-N12BB6
Type: strip to wire strip to strip joint
Dimension: 24.3*17*7.8mm 19.6*17*7.8mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃Wire
Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 12mm RGBW IP20, less than 91LEDs/M
Product Name: Hippo-M 6 Pin led strip connector
Item NO.: HR-N12XB6 HR-N12BB6
Type: strip to wire strip to strip joint
Dimension: 24.3*17*7.8mm 19.6*17*7.8mm
Max V/C: DC36V/5A
Working Temp.: -10-45℃
Wire Gauge: 22-20AWG/0.32-0.52mm2
Workable Strip: 12mm RGB CCT IP54/IP65, less than 91LEDs/M
